Abstract
Single crystalline platelets of aluminum nitride (AlN) ⩽ 1 mm thick have been grown within the temperature range of 1950–2250°C on 10 × 10 mm
2 α(6H)-silicon carbide (SiC) substrates via sublimation-recondensation in a resistively heated graphite furnace. The source material was sintered AlN. A maximum growth rate of 500 μm/h was achieved at 2150°C and a source-to-seed separation of 4 mm. Growth rates below 2000°C were approximately one order of magnitude lower. Crystals grown at high temperatures ranged in color from blue to green due to the incorporation of Si and C from the SiC substrates; those grown at lower temperatures were colorless and transparent. Secondary-ion mass spectroscopy (SIMS) results showed almost a two order of magnitude decrease in the concentrations of these two impurities in the transparent crystals. Plan view transmission electron microscopy (TEM) of these crystals showed no line or planar defects. Raman spectroscopy and X-ray diffraction (XRD) studies indicated a strain free material.
