Abstract
The increasing penetration of inverter-based resources (IBRs) to the power grid brings challenges to protection systems. IBRs may not provide sufficient fault current to trip protective relays, leading to delays in fault isolation and increased risk of equipment damage. To overcome the challenges, superimposed quantity-based elements are developed in this paper for transmission line protection in a power grid with IBRs. The characteristics of the designed protection system are tested under fault conditions in a modified IEEE 9-bus system that includes solar photovoltaic (PV) generation, and evaluated with different maximum current limits in solar PV controllers. The applied method in this paper makes contribution to the protection application for IBR-penetrated transmission systems. Simulation results show that the modeled protection system works effectively with different penetration of solar PV, and the system resilience is enhanced under fault conditions considering the tripping response and reclosing of circuit breakers.
